| Installation Type |
Junction Box |
| Dimensions without packaging (H x W x D) [mm(in.)] |
86 mm x 42.5 mm x 86 mm (3.39 in. x 1.76 in. x 3.39 in.) |
| Dimensions with packaging (H x W x D) [mm(in.)] |
117 mm x 73 mm x 98 mm (4.61 in. x 2.87 in. x 3.86 in.) |
| Weight without packaging [kg(lb)] |
0.14 kg (0.39 lb) |
| Weight with packaging [kg(lb)] |
0.24 kg (0.53 lb) |
| Maximum power consumption [W] |
9.1 |
| Power supply mode |
PoE |
| Input voltage range [V] |
PoE: 802.3af |
| Service port surge protection [kV] |
PoE port: Common mode (8 wires to ground): 4 kV (1.2/50 us, 42 ohms), criterion C |
| Maximum number of physical ports on the entire device |
GE (RJ45) x 2, 10M/100M/1000M auto-sensing |
| Long-term operating temperature [°C(°F)] |
–10°C to +40°C (14°F to 122°F) (If the altitude is in the range of 1800 m to 5000 m, the temperature decreases by 1°C or 1.8°F every time the altitude increases by 300 m.) |
| Storage temperature [°C(°F)] |
–40°C to +70°C (–40°F to +158°F) |
| Long-term operating relative humidity [RH] |
5% RH to 95% RH |
| Long-term operating altitude [m(ft.)] |
–60 m to +5000 m (–196.85 ft to +16404.20 ft) |
| Atmospheric pressure [kPa] |
53 kPa – 106 kPa ETSI 300 019-2-3 |
| Ground |
floating ground |
| Radio number |
2 |
| Operating frequency band |
• 2.4GHz • 5GHz |
| Radio interface |
Built-in smart antennas |
| Antenna gain |
2.4G: 3 dBi/chain (peak) 3 dBi (combined gain) 5G: 2 dBi/chain (peak value) 1 dBi (combined gain) |
| Maximum transmit power |
2.4G: 17 dBm/chain 20 dBm (combined power) 5G: 17 dBm/chain 20 dBm (combined power) |
| Single-frequency transmit power [dBm] |
2.4G: 0 dBm~17 dBm /chain 5G: 0 dBm~17 dBm /chain |
